Water softener sizing — calculating resin from hardness
Short answer: Softener sizing comes down to one calculation. You need the hardness of your water in ppm, your daily consumption in litres, and how many days between regenerations you want. From those three the resin volume follows, and the resin volume decides the vessel.
Step 1: Measure the hardness
This is the figure everything depends on, so do not guess it. Use a hardness test kit (4 bottle, 100 ml) at ₹1,050, or the 30 ml version at ₹656.
| Hardness (ppm as CaCO₃) | Classification |
|---|---|
| Below 75 | Soft |
| 75 – 150 | Moderately hard |
| 150 – 300 | Hard |
| Above 300 | Very hard |
Most Indian borewell water falls between 200 and 600 ppm.
Step 2: Establish daily consumption
Rough guides where you do not have a meter:
| Application | Typical consumption |
|---|---|
| Household, 4 people | 600 – 1,000 L/day |
| Small hotel, 20 rooms | 4,000 – 8,000 L/day |
| Laundry | Depends on machine load |
| Boiler feed | Steam output plus blowdown |
| Cooling tower make-up | Evaporation plus blowdown |
A flow meter on the line gives you the real figure, which is always better than an estimate.
Step 3: Decide the regeneration interval
How often are you willing to regenerate?
- Every 2 to 3 days: smaller vessel, less initial cost, more effort and more salt over time
- Every 7 to 15 days: the usual compromise
- Every 20 to 30 days: large vessel, high initial cost, but the resin sits exhausted for long periods
Most installations settle on 7 to 15 days.
Worked example
A small hotel: hardness 350 ppm, consumption 5,000 litres a day, regenerating every 10 days.
Resin = (350 × 5,000 × 10) ÷ 55,000 = 318 litres
Looking at the vessel chart, 318 litres needs a 3072 vessel (500 L capacity) — a 2469 holds only 307 L, which is just short.
Vessel selection chart
| Resin required | Vessel | Valve size |
|---|---|---|
| Up to 22 L | 0844 | 20NB |
| Up to 42 L | 1054 | 20 or 25NB |
| Up to 70 L | 1354 | 25NB |
| Up to 98 L | 1465 | 25NB |
| Up to 128 L | 1665 | 40NB |
| Up to 163 L | 1865 | 40NB |
| Up to 204 L | 2160 | 40NB |
| Up to 307 L | 2469 | 50NB |
| Up to 500 L | 3072 | 65NB |
Full details are in our vessel size chart.
Also check the flow
Resin volume is one constraint; service flow is the other. Water passing too quickly through the bed is not fully softened.
The usual limit is around 20 to 25 litres per minute per square foot of bed area. So:
- If your peak flow is high but hardness is low, size on flow
- If hardness is high but flow is low, size on resin
- Take whichever gives the larger vessel
| Vessel | Maximum service flow |
|---|---|
| 1054 | ~900 LPH |
| 1354 | ~1,500 LPH |
| 1465 | ~1,800 LPH |
| 1665 | ~2,400 LPH |
| 2160 | ~4,000 LPH |
| 2469 | ~5,500 LPH |
| 3072 | ~8,500 LPH |
The complete system
A softener is not just a vessel. You will also need:
- FRP vessel of the calculated size
- Softener multiport valve — see our MPV selection guide. Note that a filter valve will not work
- Distribution system — top distributor and laterals
- Cation resin of the calculated volume, plus graded gravel
- Brine tank with a brine director
- Vacuum breaker — ₹210
Salt consumption
Roughly 100 to 150 grams of salt per litre of resin per regeneration. For the example above with 255 litres of resin, that is around 30 kg per regeneration, and regenerating every 8 days works out to roughly 115 kg of salt a month.
This is worth calculating before ordering, because salt is a recurring cost.
Common sizing mistakes
- Guessing the hardness — a test kit costs ₹656 and removes all doubt
- Using average flow instead of peak flow — the softener has to cope with peak demand
- Choosing too long an interval — a very large vessel costs more and the resin sits exhausted
- Ignoring the flow limit — a vessel correctly sized on resin may still be too small on flow
- Forgetting the salt cost — a large softener regenerating frequently uses a lot of salt
Our free plant calculators will do this calculation for you.
Have your softener sized
Send your hardness, daily consumption and peak flow, and we will size the complete system with a quotation.
💬 WhatsApp par poochhein 📞 9910646957Frequently asked questions
How do I calculate the resin volume for a softener?
Multiply the hardness in ppm by the litres used per day and by the days between regenerations, then divide by fifty five thousand. For example three hundred and fifty ppm at five thousand litres a day over ten days needs three hundred and eighteen litres of resin.
How do I find out my water hardness?
Use a hardness test kit, which costs from about six hundred and fifty rupees. Guessing is the most common sizing mistake, because the whole calculation depends on this figure.
What regeneration interval should I choose?
Most installations settle on seven to fifteen days. A shorter interval means a smaller vessel but more effort and more salt over time, while a very long interval means a large expensive vessel with the resin sitting exhausted.
Should I size the softener on flow or on resin volume?
Check both and take whichever gives the larger vessel. If peak flow is high but hardness low, flow decides it. If hardness is high but flow low, the resin volume decides it.
How much salt will a softener use?
Roughly one hundred to one hundred and fifty grams per litre of resin per regeneration. It is worth calculating the monthly figure before ordering, because salt is a recurring cost.
